Basic class for Timoshenko Beam plugin object. More...
#include <lemMechanicalTBeam.h>
Public Member Functions | |
| LemMechanicalTBeam (const char *pluginType, GmSimulationData *simulation, QString id, QString description, const GmpFemPhysicsCommonMaterialFactory *matFactory, const GmLogCategory &logger) | |
| Constructor. Will be called by the plugin loading code. | |
| virtual | ~LemMechanicalTBeam () |
| Destructor. | |
| virtual const QVariantMap * | physicsMetaDataMap () |
| Returns a map with physic associated properties. More... | |
| virtual bool | beforeElementStiffnessLoop (const GmpFemMatrixSet &elemMatrices, const GmpFemVectorSet &elemVectors) |
| See comments on the base class. | |
| virtual FemResultType | fillElementData (const GmElement *e, GmpFemMatrixSet &elemMatrices, GmpFemVectorSet &elemVectors) |
| Fills elemental matrices and vectors. More... | |
| virtual double | fillBuMatrix (const GmElement *e, const GmShape *shape, const GmVector &ncoord, const GmMatrix &X, const GmVector &N, const GmMatrix &J, GmMatrix &Bp) |
| Fills the Strain-Displacement matrix. | |
| virtual bool | calcDerivedResults (bool nonLinearSolver) |
| Fills calculated results. More... | |
 Public Member Functions inherited from LemMechanicalPhysics | |
| LemMechanicalPhysics (const char *pluginType, GmSimulationData *simulation, QString id, QString description, const GmpFemPhysicsCommonMaterialFactory *matFactory, const GmLogCategory &logger) | |
| Constructor. Will be called by the plugin loading code. | |
| virtual | ~LemMechanicalPhysics () |
| Destructor. | |
| virtual const char * | pluginName () const |
| virtual const char * | pluginType () const |
| virtual bool | fixedNodalForcesBc (QList< int > &nodes, QList< int > &dof, QList< double > &values) const |
| See comments on base class. Fills vectors with prescribed nodal concentrated forces. | |
| virtual bool | fixedNodalDofsBc (QList< int > &nodes, QList< int > &dof, QList< double > &values, bool *constantValues) const |
| See comments on base class. Fills vectors with prescribed node displacements. | |
| void | fillElementDisplacements (const GmElement *e, GmVector &ue) |
| Given an element, fills the vector 'ue' with nodal displacements. The vector should have size equal to n * d where n is the number of element nodes and d is the node dimension. More... | |
| virtual void | fillMiddleCoordinates (const GmElement *e, GmMatrix Xnode, GmMatrix &MX) const |
| virtual double | axisSymetricFactor (const GmElement *e, const GmMatrix &X, const GmVector &N) |
| Returns the factor that should be applied when using axis symetric elements. 1.0 for other etypes. | |
| virtual bool | isPlaneStress () const |
| Returns TRUE for plane stress analysis and FALSE in other cases. More... | |
| virtual unsigned | stress_state (void) |
| Returns the number of stress components. More... | |
| GmMatrix & | dep () |
| Returns a reference to the physics constitutive tangent matrox. | |
Protected Member Functions | |
| virtual bool | checkAndLoadAttributeAccessors (LuaTable &nodeTable, LuaTable &gaussTable) |
| Loads attribute accessors. More... | |
Additional Inherited Members | |
| Public Types inherited from LemMechanicalPhysics | |
| enum | PhysicsAttributeIds { ISOPARAMETRIC_ID, NUM_ATTRI_IDS } |
| IDs for physics attributes. More... | |
| enum | StateVarIds { U_ID, W_ID, NUM_STATEVAR_IDS } |
| IDs for Mechanical physics state vars. More... | |
| enum | NodeAttributeIds { S_NA_ID, E_NA_ID, NUM_NA_IDS } |
| IDs for physics node attributes. More... | |
| enum | GaussAttributeIds { S_GA_ID, SOLD_GA_ID, E_GA_ID, EOLD_GA_ID, ST_GA_ID, STOLD_GA_ID, NUM_GA_IDS } |
| IDs for physics Gauss attributes. More... | |
| enum | ElementPropertyIds { AREA_ID, NUM_PROPER_IDS } |
| IDs for physics element properties. More... | |
| enum | BoundaryConditionIds { FIXED_U_BC_ID, FIXED_CF_BC_ID, NUM_BC_IDS } |
| IDs for accepted boundary condition types. More... | |
| enum | BoundaryConditionValueIds { BC_UX_ID, BC_UY_ID, BC_UZ_ID, BC_CF_ID, NUM_BCV_IDS } |
| IDs for property values from accepted boundary condition types. More... | |
| Protected Attributes inherited from LemMechanicalPhysics | |
| lemMechanicPoint * | _mechanicPoint |
| Access to mechanical material point. | |
| GmMatrix | _Dep |
| Constitutive tangent matrix (2 x 2) | |
Basic class for Timoshenko Beam plugin object.
|
virtual |
Fills calculated results.
Calc stress component on nodes and/or Gauss points, ADDING the calculated value to the current result.
Reimplemented from LemMechanicalPhysics.
|
protectedvirtual |
Loads attribute accessors.
Reimplementation of the common function to init the _mechanicPoint structure.
|
virtual |
Fills elemental matrices and vectors.
Fills the element matrices and vectors for a generic elements.
Implements LemMechanicalPhysics.
|
virtual |
Returns a map with physic associated properties.
Returns a reference for the single mechanical physics attribute map, built when the function is called for the first time.
Reimplemented from LemMechanicalPhysics.
